Description
| TECHNICAL DATA | ES | ||||||||
| Max hose size | 2″6S | ||||||||
| Swaging range(mm) | Φ 6-87 | ||||||||
| Master die shoe length(mm) | 85 | ||||||||
| Standard voltage | 380V/50Hz | ||||||||
| Motor power | 4kW | ||||||||
| Optional voltage &motor | 220V/2.2kW | ||||||||
| Pump(l/min) | 19L | ||||||||
| Number of swagings/hour | 1000 | ||||||||
| Noise level (dB) | 70 | ||||||||
| Max opening(mm) | Φ+34mm | ||||||||
| Crimping force(kN) | 5260 | ||||||||
| Electric limit switch | include | ||||||||
| Electronic control | include | ||||||||
| Electric pedal | include | ||||||||
 Manual change | include | ||||||||
| Dimensions LxWxH(mm) | 685x530x1320 | ||||||||
| Weight without oil | 350Kg | ||||||||
 Dispenser | Optional | ||||||||
 Quick change | Optional | ||||||||
 Longer | Optional | ||||||||
 Special dies | Optional | ||||||||
