Top Manufacturer Ac Hose Crimping Machine Hose Crimping Machine Hydraulic Hose Fitting Crimper For sale

Description

Brief Introduction

Model DX68 hose crimping machine is mainly used for buckling processing for high pressure rubber pipe assembly in the mechanical engineering. It can also be used for buckling the two-way bends, especially large bends and irregular shape bends.

This machine features small and portable appearance, big force, low noise and easy to oper- ate. The buckling amount can be precise adjusted through a scale. It makes the mould base division to be more even through the double inclined plane eight-flap mould seat equipped with a high accuracy guiding device.

Main Technical Feature

Buckling range: Φ4mm-Φ51mm(2 layers steel wire rubber hose) Max. buckling force: 449T

Scale accuracy: 0.02mm Rated pressure: 31.5 MPa

Oil pump displacement: 5ml/rad (380V); 2.5ml/rad (220V) Overall dimensions: 670(L)×490(W)×780(H)mm

Hose crimping machine
Model	DX68	DX76	DX102	DX150
Crimping range	6-51mm(1/4″ ~2″)	6~76mm ( 1/4~3″ )	6~102mm ( 1/4~4″ )	6-150mm(1/4~6″)
Max crimping Force	449T	500T	1400T	2500T
Rated Pressure	31.5MPa	50Mpa	31.5Mpa	31.5Mpa
Weight	250kg	300kg	520kg	900kg
Mold Quantity	10 sets	13Sets	16Sets	17Sets
Power	3KW/4KW	4KW	4KW/5.5KW/7.5KW	4KW/5.5KW/7.5KW
Voltage	220V/380V	240V / 380V	380V or customized	380V or customized
Scale accuracy	0.02mm	0.02mm	0.01mm	0.01mm
Overall dimensions	670490780mm	730470930mm	9007901070mm	1030630 1160mm

Main Technical Feature

1.Efficient, fast pump
2. dies can be changed quickly by QC tool
3. Die set rack,space saving.
4. Precision control device,equipped with signal lamp
5. automatic&semi-auto&button& foot pedal control operated
6.The height of the machine is just right for standing operation

Notices

1.When buckling, make the joint to locate the mould center as much as possible, the joint is not buckled on the hex nut.

2.Prevent tool and other foreign matter from entering the locking head.

3.After the work is finished for each time, the eight-block mould base must be made to extend to the greatest extent, this can make the spring to be at extension status. If not, the spring will be damage.

4.When working, the hand should not stretch into the locking head.

5.The power supply must be switched off when maintenance is done.

Maintenance and Care

Maintenance

The hydraulic oil in the oil tank should be frequently checked, if oil amount is found to be insuf- ficient, the oil shall be timely supplemented. If the oil liquid is polluted, it shall be filtered or replaced.

The locking head shall keep internal cleanliness. Avoid the foreign matters during processing to enter into the locking head oil cylinder via the mould to affect the normal use. Wipe out the foreign matters, which are brought by the mould body in time when buckling the joint.

Frequently fill suitable grease into the mould body for lubrication.

Promise

We will provide a guarantee to keep the machine in good repair within 12 months from the day when the machine is purchased. All fitting troubles will be free of charge repaired (or replaced if necessary) during the guarantee period. The damage resulted from improper use o accident damage does not belong to free of charge repair range.

About Hydraulic Hose Fitting Crimper

A hydraulic hose fitting crimper is a tool used to crimp hydraulic hose fittings onto hydraulic hoses. Hydraulic hoses are used to transmit high-pressure fluids in hydraulic systems, and they require a secure connection between the hose and the fitting to prevent leaks and ensure the proper functioning of the system.

Hydraulic hose fitting crimpers come in different sizes and types, from handheld portable units to larger, more complex machines used in industrial applications. They work by compressing the fitting onto the hose using a hydraulic press, which deforms the fitting and creates a tight, leak-free seal.

It’s important to use the correct crimping tool and fittings for your specific application, as well as to follow the manufacturer’s instructions for crimping to ensure a secure and reliable connection. Improperly crimped fittings can lead to leaks, system failure, and even personal injury.

Overall, hydraulic hose fitting crimpers are an essential tool for any hydraulic system that requires hoses and fittings, and they are commonly used in industries such as construction, agriculture, manufacturing, and transportation.

About Hydraulic Pipe Pressing Machine Manufacturer

There are many manufacturers of hydraulic hose fitting crimpers, each offering a variety of models and options to suit different applications and budgets. Here are some well-known hydraulic hose fitting crimper manufacturers:

Parker Hannifin – Parker is a global manufacturer of motion and control technologies, including hydraulic hose and fittings, and they offer a range of hydraulic hose fitting crimpers.
Gates Corporation – Gates is a leading manufacturer of power transmission and fluid power products, including hydraulic hose and fittings, and they offer a range of hydraulic hose fitting crimpers.
Eaton – Eaton is a global manufacturer of power management technologies, including hydraulic hose and fittings, and they offer a range of hydraulic hose fitting crimpers.
Finn-Power – Finn-Power is a manufacturer of hydraulic hose crimping machines, and they offer a wide range of models and options for different applications.
UNIFLEX – UNIFLEX is a German manufacturer of hydraulic hose crimpers, and they offer a range of manual, hydraulic, and electric models for different applications.

There are many other manufacturers of hydraulic hose fitting crimpers, and it’s important to choose a reputable manufacturer and model that is appropriate for your specific application. It’s also important to follow the manufacturer’s instructions for use and maintenance to ensure a safe and reliable operation of the tool.

HengHua is a professional manufacturer, supplier of Hydraulic Hose Fitting Crimper, we provide Hydraulic Hose Fitting Crimper OEM & ODM wholesale, Hydraulic Hose Fitting Crimper price and more questions, please contact us and follow our Facebook:https://www.facebook.com/Henghuahose and Youtube:https://www.youtube.com/@HENGHUA-let-crimp-easier , We will respond in a timely manner, we are not the lowest price of DX68 Hydraulic Hose press machine, but we will provide you with better service.

We are Chine Top Verified Manufacturer of rubber hose making machinery, If you follow this industry, you can always see our products. we have better quality, technology and competitive prices in the similar product. If you are interested in our product, please feel free to contact us. Thanks!

Additional information

Model	DX68
Crimping range	6-51mm(1/4" ~2")
Max crimping Force	449T
Rated Pressure	31.5MPa
Weight	250kg
Mold Quantity	10 sets
Power	3KW/4KW
Voltage	220V/380V
Scale accuracy	0.02mm
Overall dimensions	670490780mm
